Santa Cruz V10 CC DH S MX

Santa Cruz V10 CC DH S MX
Please select options
Sorry, this item is currently not available. Please check back soon - or call us at 781-447-7223.

Details

Puzzling Ain't Easy

The V10 is designed to be exactly the right bike for anyone who steps up to the start line with eyes on a podium. The racer who chooses a V10 is the recipient of every bit of work and puzzling that's gone into the Syndicate's race bikes.

The continuous fine-tuning that the V10 has undergone with the Syndicate for World Cup season after season has guaranteed regular, high-level feedback. The result is perhaps the most refined suspension performance available outside of a World Cup pit. 215mm of VPP travel is exquisitely refined, and the ease of tuning and serviceability of the VPP system makes it a hit in the pits with mechanics and privateers.

Wheel size has been the latest puzzle to ponder. Greg Minnaar, being a tall rider looking for pure speed on the clock, focuses his choice on 29-inch wheels. Luca Shaw chose what feels fun, because, to him, if he's having fun he's going fast, so he's on a mixed setup. Bottom line: your V10 is optimized for who you are.

The most successful bike in downhill history shows no signs of slowing down.

High Setting
bike frame with labeled dimensions
Bike Sizes:
ML
A. Reach 437mm 462mm
B. Stack 632mm 637mm
C. Standover 718mm 719mm
E. Head Tube Angle 63.7° 63.7°
F. Head Tube Length 100mm 105mm
H. Seat Tube Length 445mm 455mm
I. Bottom Bracket Height 356mm 356mm
J. Bottom Bracket Drop 16.4/-2mm 16.4/-2mm
M. Wheelbase 1251mm 1278mm
N. Front to Center 806mm 833mm
O. Chainstay Length 445-455 445-455

Low Setting
bike frame with labeled dimensions
Bike Sizes:
ML
A. Reach 435mm 460mm
B. Stack 631mm 635mm
C. Standover 713mm 714mm
E. Head Tube Angle 63.3° 63.3°
F. Head Tube Length 100mm 105mm
H. Seat Tube Length 445mm 455mm
I. Bottom Bracket Height 351mm 351mm
J. Bottom Bracket Drop 21.6/3.mm 21.6/3.mm
M. Wheelbase 1252mm 1279mm
N. Front to Center 806mm 833mm
O. Chainstay Length 446-456 446-456

Specs

Frame S MX
Fork Fox 40 Performance, 203mm, 29"
Rear Shock RockShox Super Deluxe Coil Select+ (400 S, 450 M, 500 L-XL, 550 XXL)
Rims RaceFace ARC HD 30 29" (F) RaceFace ARC HD 30 27.5” (R)
Hubs Front: DT Swiss 350, 20x110, Boost, 32h
Rear: DT Swiss 350 ISO, 12x157, HG, 32h
Spokes Sapim Race
Axles Front: 110 x 15mm
Rear: 148 x 12mm
Tires Front: Maxxis Assegai 29"x2.5", 3C, MaxxGRIP
Rear: Maxxis Assegai 27.5"x2.5", 3C, MaxxGRIP
Bottom Bracket SRAM DUB 83mm
Crankset SRAM Descendant DH, 165mm
Chainrings 36t
Shifters SRAM GX, 7spd
Rear Derailleur SRAM GX DH, 7spd
Cassette/Freewheel SRAM PG720 DH, 11-25t
Chain SRAM PC1110, 11spd
Brakes SRAM Code R
Rotors SRAM Centerline Rotor 203mm (F) / 200mm (R)
Handlebars Burgtec RideWide DH Alloy Bar, 800mm, 30mm Rise
Tape/Grips Burgtec Bartender Pro Grip Minnar or VP VPG-101A
Stem Santa Cruz Direct Mount 35x45/50
Headset Cane Creek 40 ZS49/EC49 Headset
Seatpost RaceFace Chester
Saddle Fizik Alpaca Gravita X5 Saddle or WTB Volt
Pedals Sold separately
Accessories & Extras E13 Vario DH Guide

* Subject to change without notice.
