Santa Cruz V10 CC DH S

Santa Cruz V10 CC DH S
Please select options
Sorry, this item is currently not available. Please check back soon - or call us at 781-447-7223.

Details

Puzzling Ain't Easy

The V10 is designed to be exactly the right bike for anyone who steps up to the start line with eyes on a podium. The racer who chooses a V10 is the recipient of every bit of work and puzzling that's gone into the Syndicate's race bikes.

The continuous fine-tuning that the V10 has undergone with the Syndicate for World Cup season after season has guaranteed regular, high-level feedback. The result is perhaps the most refined suspension performance available outside of a World Cup pit. 215mm of VPP travel is exquisitely refined, and the ease of tuning and serviceability of the VPP system makes it a hit in the pits with mechanics and privateers.

Wheel size has been the latest puzzle to ponder. Greg Minnaar, being a tall rider looking for pure speed on the clock, focuses his choice on 29-inch wheels. Luca Shaw chose what feels fun, because, to him, if he's having fun he's going fast, so he's on a mixed setup.

Wheel size:
- Size Small: 27.5-inch
- Sizes Medium – X-Large: 29-inch

Bottom line: your V10 is optimized for who you are.

The most successful bike in downhill history shows no signs of slowing down.

High Setting
bike frame with labeled dimensions
Bike Sizes:
SML
A. Reach 412mm 437mm 462mm
B. Stack 603mm 612mm 616mm
C. Standover 712mm 712mm 712mm
E. Head Tube Angle 63.7° 63.7° 63.7°
F. Head Tube Length 100mm 110mm 115mm
H. Seat Tube Length 435mm 445mm 455mm
I. Bottom Bracket Height 356mm 356mm 356mm
J. Bottom Bracket Drop -2mm -2mm -2mm
M. Wheelbase 1199mm 1233mm 1265mm
N. Front to Center 769mm 798mm 825mm
O. Chainstay Length 430mm 435mm 440mm
Low Setting
bike frame with labeled dimensions
Bike Sizes:
SML
A. Reach 410mm 435mm 460mm
B. Stack 602mm 610mm 615mm
C. Standover 707mm 707mm 707mm
E. Head Tube Angle 63.3° 63.3° 63.3°
F. Head Tube Length 100mm 110mm 115mm
H. Seat Tube Length 435mm 445mm 455mm
I. Bottom Bracket Height 351mm 351mm 351mm
J. Bottom Bracket Drop 3mm 3mm 3mm
M. Wheelbase 1200mm 1234mm 1266mm
N. Front to Center 769mm 798mm 825mm
O. Chainstay Length 430mm 435mm 440mm
High Setting
bike frame with labeled dimensions
Bike Sizes:
MLXL
A. Reach 437mm 462mm 492mm
B. Stack 632mm 637mm 641mm
C. Standover 718mm 719mm 719mm
E. Head Tube Angle 63.7° 63.7° 63.7°
F. Head Tube Length 100mm 105mm 110mm
H. Seat Tube Length 445mm 455mm 465mm
I. Bottom Bracket Height 356mm 356mm 356mm
J. Bottom Bracket Drop 16mm 16mm 16mm
M. Wheelbase 1251mm 1278mm 1315mm
N. Front to Center 806mm 833mm 865mm
O. Chainstay Length 445mm 445mm 450mm

Low Setting
bike frame with labeled dimensions
Bike Sizes:
MLXL
A. Reach 435mm 460mm 490mm
B. Stack 631mm 635mm 640mm
C. Standover 713mm 714mm 714mm
E. Head Tube Angle 63.3° 63.3° 63.3°
F. Head Tube Length 100mm 105mm 110mm
H. Seat Tube Length 445mm 455mm 465mm
I. Bottom Bracket Height 351mm 351mm 351mm
J. Bottom Bracket Drop 21mm 21mm 21mm
M. Wheelbase 1252mm 1279mm 1316mm
N. Front to Center 806mm 833mm 865mm
O. Chainstay Length 445mm 445mm 450mm

Specs

Frame S 27.5/29
Fork Fox 40 Performance, 203mm
Headset Cane Creek 40 ZS49/EC49 Headset
Rear Shock Fox DHX2 Performance Elite Coil
Axles Front: 110 x 15mm
Rear: 148 x 12mm
Rims/Wheels RaceFace ARC HD 30 Rims
Hubs Front: DT Swiss 350, 20x110, Boost, 32h
Rear: DT Swiss 350 ISO, 12x157, HG, 32h
Spokes Sapim Race
Tires Maxxis Assegai 2.5", 3C, MaxxGRIP
Crankset SRAM Descendant DH, 165mm
Chainrings 36t
Bottom Bracket SRAM DUB 83mm
Chain SRAM GX, 7spd
Rear Derailleur SRAM GX DH, 7spd
Cassette/Rear Cogs SRAM PG720 DH, 11-25t
Shifters SRAM PC1110, 11spd
Handlebars Burgtec RideWide DH Alloy Bar, 800mm, 30mm Rise
Tape/Grips Burgtec Bartender Pro Grip Minnar or VP VPG-101A
Stem Santa Cruz Direct Mount 35x45/50
Brakes SRAM Code R, SRAM Centerline Rotor 203mm (F) / 200mm (R)
Saddle Fizik Alpaca Gravita X5 Saddle or WTB Volt
Seat Post RaceFace Chester
Accessories & Extras E13 Vario DH Guide

* Subject to change without notice.
