Santa Cruz Jackal Frame

Santa Cruz Jackal Frame
Please select options
Sorry, this item is currently not available. Please check back soon - or call us at 781-447-7223.

Details

Jackal is an opportunistic scavenger of man-made terrain.

The Jackal is a no-BS dirt jump, pump track, and urban assault bike. We sell it as a frame-only, and it runs on old-timey 26-inch wheels.

Overbuilt to last forever, these frames will take more abuse than you can dish out, yet still weigh in at under 5lbs.

A clever asymmetrical yoke permits the use of rock-solid and super-short 15.2-inch chainstays. And, for those who want to take their anarchy further afield, the unique sliding rear dropouts allow for a geared set-up as well as single speed.

- Frame only

bike frame with labeled dimensions
Bike Sizes:
ML
A. Reach 391.6mm 417mm
B. Stack 563.2mm 563.2mm
C. Standover 630mm 627mm
D. Effective Top Tube 571.5mm 596.9mm
E. Head Tube Angle 68.7° 68.7°
F. Head Tube Length 115mm 115mm
G. Seat Tube Angle 72.7° 72.7°
H. Seat Tube Length 340mm 340mm
I. Bottom Bracket Height 323.8mm 323.8mm
M. Wheelbase 1031.5mm 1056.9mm
O. Chainstay Length 571.5mm 596.9mm

Specs

Frame Jackal
Fork 100-160mm
Wheels 26-inch
Tires 2.5-inch max
Bottom Bracket 73mm threaded
Front Derailleur No compatibility
Headset Mixed taper 1.5" Lower, 1-1/8" upper
Seatpost 30.9mm

* Subject to change without notice.
