Santa Cruz Highball C S

Santa Cruz Highball C S
Please select options
Sorry, this item is currently not available. Please check back soon - or call us at 781-447-7223.

Details

Wide open, dawn to dusk.

The Highball is our flagship carbon hardtail race thoroughbred, and a dark horse in XC versatility.

More capable than a pure endurance bike, more composed than most XC race-rigs, the Highball has evolved to be easier to ride harder for longer. We fine-tuned the carbon layup process and the low-angle, bridgeless seatstays join the seat tube below the top tube junction in order to curb trail chatter.

Built around a 27.2mm diameter seat post, the whole package combines to take the "hard" out of hardtail riding. It has the mindset of a race bike but it's prepared for more. With capacity for three bottle cages, the ever-reliable threaded BB, and of course, the lifetime warranty that comes standard with all Santa Cruz bikes, it's the kind of bike that'll go far.

bike frame with labeled dimensions
Bike Sizes:
A. Reach 405mm 430mm 450mm 480mm
B. Stack 596mm 606mm 615mm 634mm
C. Standover 708mm 715mm 740mm 756mm
D. Effective Top Tube 587mm 615mm 638mm 674mm
E. Head Tube Angle 69.5° 69.5° 69.5° 69.5°
F. Head Tube Length 90mm 100mm 110mm 130mm
G. Seat Tube Angle 73° 73° 73° 73°
H. Seat Tube Length 405mm 430mm 470mm 530mm
I. Bottom Bracket Height 314mm 314mm 314mm 314mm
J. Bottom Bracket Drop 56mm 56mm 56mm 56mm
M. Wheelbase 1088mm 1116mm 1140mm 1177mm
N. Front to Center 662mm 690mm 714mm 751mm
O. Chainstay Length 426mm 426mm 426mm 426mm

Specs

Frame S
Fork RockShox Sid SL Select+, 100mm w/ Remote
Rims RaceFace AR Offset 27 29" Rims
Hubs Front: DT Swiss 370, 15x110, Torque Cap, 6 bolt, 28h or E13 SL
Rear: DT Swiss 370, 12x148, XD, 28h or E13 SL
Spokes Sapim Race
Axles Front: 110 x 15mm
Rear: 148 x 12mm
Tires Front: Maxxis Aspen, 29"x2.4WT, EXO, TR
Rear: Maxxis Aspen, 29"x2.35, EXO, TR
Bottom Bracket SRAM DUB 68/73mm
Crankset SRAM GX Eagle 148 DUB
Chainrings 34t
Shifters SRAM GX Eagle
Front Derailleur SRAM OneLoc
Rear Derailleur SRAM GX Eagle, 12spd
Cassette/Freewheel SRAM XG1275 Eagle, 12spd, 10-50t
Chain SRAM GX Eagle, 12spd
Brakes SRAM Level TL
Rotors Avid Centerline 160mm
Handlebars SRAM Atmos Flat Bar, 31.8x760
Tape/Grips ESI Chunky
Stem SRAM Atmos Stem, 60mm
Headset Cane Creek 40 IS Integrated
Seatpost RaceFace Next
Saddle WTB Silverado Pro Saddle or WTB Volt
Pedals Sold separately

* Subject to change without notice.
