Juliana Joplin AL Frame

Juliana Joplin AL Frame
Please select options
Sorry, this item is currently not available. Please check back soon - or call us at 781-447-7223.

Details

A little bit (cross) country. A little bit rock and roll.

The Joplin is a bit of an XC wild child, a light bike that's heavy on capability with a "let's go" attitude to any trail.

Let's go fast. Let's go far. Let's go until your legs are ready to give up, and then go some more. Let's make every second count. Let's carve rides out of busy days and put those lines on the map on your done list.

The Joplin's 29-inch wheels and lean frame float over washboard bumps with the same ease with which it devours jagged ledges. A geometry bred for long days in the saddle is blended with 130mm of travel in the front and 120mm in the rear, creating a capable climber that doesn't flinch when roots get ragged and rocks start to roll. The lower link VPP suspension offers a responsive pedaling platform that's ready to get up and go the moment you are. Whether you're flossing rock gardens or making the rider in front of you your next hare, the Joplin is one rapid little trail fox that will take you farther than you thought you could and give you the confidence to go bigger than you thought you would.

With a size range that starts at XS, this bike brings big-wheel benefits to those of us in the fun-size category,, too. And, yes, every size in the line fits a water bottle inside the main triangle because XS doesn't mean "do things by half".

So, what are you waiting for? Let's go!

High Setting
bike frame with labeled dimensions
Bike Sizes:
XSSM
A. Reach 400mm 425mm 450mm
B. Stack 592mm 601mm 610mm
C. Standover 681mm 696mm 708mm
D. Effective Top Tube 539mm 567mm 596mm
E. Head Tube Angle 65.7° 65.7° 65.7°
F. Head Tube Length 90mm 100mm 110mm
G. Seat Tube Angle 76.8° 76.7° 76.6°
H. Seat Tube Length 370mm 380mm 405mm
I. Bottom Bracket Height 335mm 335mm 335mm
J. Bottom Bracket Drop 38mm 38mm 38mm
M. Wheelbase 1129mm 1158mm 1187mm
N. Front to Center 699mm 728mm 757mm
O. Chainstay Length 436mm 436mm 436mm

Low Setting
bike frame with labeled dimensions
Bike Sizes:
XSSM
A. Reach 398mm 423mm 448mm
B. Stack 593mm 603mm 612mm
C. Standover 678mm 692mm 704mm
D. Effective Top Tube 540mm 568mm 597mm
E. Head Tube Angle 65.5° 65.5° 65.5°
F. Head Tube Length 90mm 100mm 110mm
G. Seat Tube Angle 76.5° 76.4° 76.3°
H. Seat Tube Length 370mm 380mm 405mm
I. Bottom Bracket Height 332mm 332mm 332mm
J. Bottom Bracket Drop 41mm 41mm 41mm
M. Wheelbase 1128mm 1157mm 1187mm
N. Front to Center 698mm 727mm 757mm
O. Chainstay Length 436mm 436mm 436mm

Specs

Frame Joplin Aluminum
Fork 130-140mm
Rear Shock FOX Float Performance DPS
Wheels 29-inch
Axles 12x148mm
Tires 2.6-inch max
Bottom Bracket 73mm threaded
Chainrings 36t max
Front Derailleur No compatibility
Brakes 180 PM
Headset Integrated (IS41/52)
Seatpost 31.6mm

* Subject to change without notice.
