Details
The perfect match to get you out of the neighborhood and into the skatepark.
Size | A. Head Angle | B. Seat Angle | C. Top Tube | D. Seat Tube | E. Chainstay | F. BB Height | G. Stand Over |
---|---|---|---|---|---|---|---|
18.5 | 74.5° | 70° | 18.5" (470mm) | 10.2" (260mm) | 13.7" (349mm) | 11.5" (293mm) | 21.5" (546mm) |
20.5 | 74.5° | 70° | 20.5" (520mm) | 10.2" (260mm) | 13.7" (349mm) | 11.5" (293mm) | 21.5" (546mm) |
Specs
Pedals | Poly Platform, Cr-Mo 9/16" Axle |
---|---|
Fork | Full Hi-Ten 1 1/8" Threadless w/ Tapered Legs |
Hubs | F: Steel Shell 36h, Loose Ball / R: Alloy Shell Cassette, 36h, Loose Ball w/ Sealed Bearing Driver |
Stem | Haro Baseline 48mm Reach |
Chain | Baseine Chain |
Frame | Full Hi-Ten Frame |
Tires | Haro MS5 20 x 2.3" |
Brakes | Alloy 990 U-Brake |
Saddle | Haro Padded Adjustable |
Wheels | 20" Alloy 36h, Single Wall |
Headset | Threadless Loose Ball, 1 1/8" |
Crankset | Haro Baseline 3-pc Cr-Mo 8 Spline 165mm / 170mm - 25t Steel Chainring |
Seatpost | Steel, 25.4mm |
Chainrings | 25T Steel |
Handlebars | Full Hi-Ten, 7.5" Rise / 8.25" Rise |
Tape/Grips | Baseline Grips |
Brake Levers | Haro Baseline Alloy Hinged Lever |
Bottom Bracket | Loose Ball American BB |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Matte Black / 20.5-inch / 20-inch | 691840232449 | 23244 | 65116 |
Honey Mustard / 20.5-inch / 20-inch | 691840232456 | 23245 | 63214 |
Black/Red / 20.5-inch / 20-inch | 691840232463 | 23246 | 63617 |
